HSK 63E ER40 Long Style Tool Holder P/N H29-G-L

HSK 63E Tool holder with nut

DIN 69893

Collet Type: ER40    Capacity 3 to 30 mm

Dimensions (mm): L: 100   L1: 83.5   D: 63

Call for back order status or multiple order discount.

1-714-307-2332 or send inquiries to sales@hsspindles.com

Out of stock

Original price was: $240.00.Current price is: $216.00.

Out of stock

HSK 63E Tool Holder with Nut

P/N H29-G-L Specifications:

HSK 63E Tool Holder Collet Size: ER40

Material: Through hardened alloy steel. Precision ground surfaces.

Manufacturer: Made in Italy.

Recommended Torque: 133 ft/lbs

Balance Grade: G2.5 @ 24,000 rpm

Maintenance: Protect from rust with rust preventative spray. Remove spray before placing into service. Use correct concentration of coolant to prevent corrosion. Always check tool holders for scoring or wear. Replace if worn or damaged.

Compatibility: All HSK 63E spindles.

Dimensions (mm): L: 100    L1: 83.5     D: 63

Equivalent to IMS P/N WE222-L100

Notes: HSK tooling offers advantages over ISO tooling. Read here for more information.

HSK World: HSK Links

Weight 1.41 lbs
Dimensions 2.73 × 2.73 × 3.12 in
